Install and setup : kafka manager

Created 월요일 04 12월 2017
A tool for managing Apache Kafka.

Installation/Setup/Configuration

1. Pre-installation setup

A. creating required operating system group and user

create the os application group(typically, app)

$ groupadd -g 3000 app

어플리케이션 단위 관리 주체가 다르지 않고 권한을 나눌 필요가 없어 통합 계정을 생성하여 관리 어플리케이션 단위 관리 주체가 다르다면 어플리케이션별 계정을 생성하여 생성하여 관리

create the software unified account (typically, app)

$ useradd -d /apps -g 3000 -m -u 3000 -s /bin/bash app $ passwd app

create the kafka software owner (typically, kafka)

$ useradd -d /apps/kafka -g 3000 -m -u 3460 -s /bin/bash kafka
$ passwd kafka

B. Requirements and install dependency packages

>required JDK 1.8
>required JDK 12

required JDK 11
Try building with Java 11 since CMAK 3.x.

C. creating base directory

디렉토리 생성

$ mkdir -p /apps $ mkdir -p /apps/install $ mkdir -p /pgms $ mkdir -p /data $ mkdir -p /logs

소유권 변경

$ chown -R app:app /apps $ chown -R app:app /pgms $ chown -R app:app /data $ chown -R app:app /logs

D. firewall configuration

$ vi /etc/sysconfig/iptables

...
# kafka manager
-A INPUT -m state --state NEW -m tcp -p tcp --dport 7642 -j ACCEPT
...

restart iptalbes service

$ service iptables restart

$ iptables -nL

2. installation setup

A. change account

$ su - app

B. creating application directory

required JDK 11
$ cd /app/install
$ wget https://download.java.net/openjdk/jdk11/ri/openjdk-11+28_linux-x64_bin.tar.gz
$ tar xvf openjdk-11+28_linux-x64_bin.tar.gz.tar.gz
$ mv jdk-11 /apps/jdk/11+28
set JAVA_HOME, PATH

make directory

$ mkdir -p /apps/kafka-manager

$ mkdir -p /data/kafka-manager $ mkdir -p /logs/kafka-manager

C. download

Kafka Manager(https://github.com/yahoo/CMAK/releases)

$ cd /apps/install
$ curl -o https://github.com/yahoo/CMAK/releases/download/3.0.0.4/cmak-3.0.0.4.zip

D. install

unzip archive

$ unzip cmak-3.0.0.4.zip
$ mv cmak-3.0.0.4 /apps/kafka-manager/3.0.0.4

C. download

Kafka Manager(https://github.com/yahoo/kafka-manager)
https://github.com/yahoo/CMAK.git
$ curl -O https://github.com/yahoo/CMAK/archive/master.zip
$ wget https://github.com/yahoo/CMAK/archive/master.zip

D. install

unzip archive

$ unzip master.zip

compile/build

$ cd CMAK-master

error: SBT Assembly about MergeStrategy $ vi build.sbt

...
assemblyMergeStrategy in assembly := {
 case PathList("javax", "servlet", xs @ _*)         => MergeStrategy.first
 case PathList(ps @ _*) if ps.last endsWith ".html" => MergeStrategy.first
 case "application.conf"                            => MergeStrategy.concat
 case "unwanted.txt"                                => MergeStrategy.discard
 case x =>
   val oldStrategy = (assemblyMergeStrategy in assembly).value
   oldStrategy(x)
}
...

$ ./sbt clean dist

$ cd /apps/install/CMAK-master/target/universal
$ unzip cmak-3.0.0.4.zip
$ mv cmak-3.0.0.4 /apps/kafka-manager/3.0.0.4

E. configure

$ cd /apps/kafka-manager/3.0.0.4/conf
$ cp application.conf application.conf.default
$ vi application.conf

...
kafka-manager.zkhosts="172.20.0.102:17214,172.20.0.102:27214,172.20.0.102:37214"
...
basicAuthentication.username="admin"
basicAuthentication.password="password"
...

$ cp logback.xml logback.xml.default
$ vi logback.xml

...
   <logger name="kafka.manager" level="WARN" />
...

F. run application

start process

$ nohup /apps/kafka-manager/3.0.0.4/bin/cmak -DZK_HOSTS=”172.20.0.102:17214,172.20.0.102:27214,172.20.0.102:37214” 1>/dev/null 2>&1 &

$ /apps/kafka-manager/3.0.0.4/bin/cmak -DZK_HOSTS=”172.20.0.102:17214,172.20.0.102:27214,172.20.0.102:37214″ &

설정파일을 수정했다면…
$ nohup /apps/kafka-manager/3.0.0.4/bin/cmak 1>/dev/null 2>&1 &

$ /apps/kafka-manager/3.0.0.4/bin/cmak &

$ nohup /apps/kafka-manager/2.0.0.2/bin/kafka-manager -DZK_HOSTS=”172.20.0.102:17214,172.20.0.102:27214,172.20.0.102:37214” 1>/dev/null 2>&1 &

check process and port

$ ps -ef | grep kafka-manager

$ netstat -ntl

$ netstat -na | grep LISTEN
…
tcp 0 0 :::9000 :::* LISTEN
…

stop process

$ kill -9 `cat /apps/kafka-manager/3.0.0.4/RUNNING_PID`

Kafka Monitoring

Clusters > cluster01 > Topics

Metrics / Consumers consuming from this topic jmx 설정

kafka 기동 시 JMX_PORT를 설정해 줘야 한다.
$ env JMX_PORT=19999 /apps/kafka/2.12-2.2.0/bin/kafka-server-start.sh -daemon /apps/kafka/instances/01/config/server.properties
$ env JMX_PORT=29999 /apps/kafka/2.12-2.2.0/bin/kafka-server-start.sh -daemon /apps/kafka/instances/02/config/server.properties
$ env JMX_PORT=39999 /apps/kafka/2.12-2.2.0/bin/kafka-server-start.sh -daemon /apps/kafka/instances/03/config/server.properties

trouble-shooting

Will not attempt to authenticate using SASL (unknown error)

Kubernetes Service로 zookeeper cluster client를 설정해서 연계구성했다. 위와 같은 개발환경에서는 문제가 없는데
다음과 같이 CMAK를 기동 시

$ nohup /apps/kafka-manager/3.0.0.4/bin/cmak -DZK_HOSTS="mobon-data-zookeeper-client-svc:7214" 1>/dev/null 2>&1 &

‘Will not attempt to authenticate using SASL (unknown error)’ 메세지와 함께 클러스터가 빠져서
CMAK 화면에 클러스터가 보이지 않는다.
화면에 Add Cluster로 추가하면 잘 나오기는 하는데… 하니까 다음에 보자. ㅋ
